| Place of Origin: | China |
| Brand Name: | Nide |
| Certification: | None |
| Model Number: | ND-JF-80GD |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden case suitable for sea transportation |
| Delivery Time: | 60 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 200 sets per year |
| Name: | Electrostatic Powder Coating Machine | Condition: | New |
|---|---|---|---|
| Color: | Customized | Size: | Middle |
| High Light: | automatic powder coating machine,powder coating machinery |
||
Mini Rotor Insulating Electrostatic Powder Coating Production Line For Automotive
Quick Detail:
1, This machine is widely used in mini rotor insulating coating, such as automotive, motorcycle, power cycle, toy and small electromotor of appliance.
2, This machine is the most technical advanced product in electrostatic coating field
Applications:
This machine is widely used in mini rotor insulating coating, such as automotive, motorcycle, power cycle, toy and small electromotor of appliance.
Specifications :
|
Working piece max O.D: |
120mm |
|
Working piece max stack length |
70mm |
|
Working piece max shaft length |
180mm |
|
Recycle efficiency |
≥95% |
|
Production efficiency: |
1500pcs/hour |
|
Coating thickness: |
0.15mm-0.5mm adjustable |
|
Line speed m/min: |
0.1-1.5m adjustable |
|
Screw rod length |
3500mm |
|
Feeding speed |
0~0.5RPM |
|
Static voltage |
0~60KN |
|
Static current |
≤200μA |
|
Air source pressure |
0.5~0.7MPa |
|
Voltage |
380V three phase |
|
High frequency power |
30KW |
|
Total dimension |
4900mm*2500mm*2000 |
|
Weight |
3000Kgs |
Description:
This power coating machine is the most technical advanced product in electrostatic coating field, which is widely used in mini rotor insulating coating, such as automotive, motorcycle, power cycle, toy and small electromotor of appliance.
Working procedure:
Small motor is transported to fluid bed by screw for coating. Insulation power is equally coated on its surface, and then cured by high frequency heating. This machine consists of coating, curing, cooling and powder recycling. Except loading and unloading, the other processes are completed automatically.
Competitive advantages:
This machine has a wide application, and easy for operation. The coated armature has shiny surface, even thickness, good electricity performance.
