Automatic BLDC Motor Stator Needle Winding Machine with 4 Stations

BLDC Motor Winding Machine Description:

The needle winding machine Mainly used for multi-pole stator winding. 4 stators will be wound in each action cycle, the production efficiency is greatly improved, manual feeding, automatic clamping of the mold, reducing manual labor intensity; the winding process can realize multiple taps (screen settings), thread clamping, and thread trimming functions . The number of slots and the number of turns can be set through the man-machine interface; the all-aluminum alloy protective cover (anodized) plus imported acrylic protection; the electrical is controlled by the PCL motion module (programmable controller), the display interface, and the servo motor are The main control, setting and display are safe and reliable.

BLDC Motor Winding Machine Functions and Features:

1. It is used for multi-pole stator winding, manual loading and unloading, automatic clamping, winding, clipping and trimming;

2. The frame is made of aluminum profiles;

3. The mold fixture part adopts the lower positioning method, the positioning is stable and the tightening is reliable;

4. According to the product characteristics, manual loading and unloading, the equipment can realize automatic hooking, automatic thread trimming and automatic thread clamping;

5. Different types of molds can be quickly replaced

6. The winding parameters can be switched between different stators and the winding parameters can be quickly switched through the man-machine interface in order to adapt to the requirements of different stators;

7. All aluminum alloy protection;

8. PLC motion module control (programmable controller), fault display;

9. The machine adopts safety grating protection system and safety door switch protection;

10. The safety indicators of the equipment comply with CE standards.

BLDC Motor Winding Machine Technical Parameter:

BLDC Motor Winding Machine Application

The stator needle winding machine is suitable for BLDC Motor Stator manufacturing.It has been widely used in many fields such as automobiles, household appliances, aircraft models, medical equipment, office automation and so on.
